Femtosecond Fiber Lasers

Best in class femtosecond fiber lasers: highest output power, lowest phase noise, highest reliability. Choose the perfect model for your application from our Erbium and Ytterbium fiber lasers with center emission wavelengths from the visible to the NIR, and extending to the Mid-IR in selected models.



What‘s new in femtosecond fiber lasers New Features 2024 Wavelengths from the mid-infrared region to 520 nm and beyond: learn more about the latest lasers for academic research and industrial applications.
Robust.Reliable.Ready-to-use Portfolio Overview Perfectly aligned to scientific as well as industrial / OEM settings.
Why 9 cuts a good figure Technology Primer Key benefits of our proprietary figure 9® mode locking technology
Specials Menlo Systems Femtosecond Fiber Lasers Watch our latest video on our femtosecond fiber laser technology
1560 nm, 500-2200 nm C-Fiber Femtosecond Erbium Laser.
Ultrafast Laser for Amplifier Seeding and Spectroscopy.
  • Wavelength: 1560 nm
  • Average Power: >500 mW
  • Pulse Duration: <90 fs
  • Repetition Rate: 50 -250 MHz



780 nm, 1560 nm C-Fiber 780 Femtosecond Erbium Laser.
Ultrafast Laser for Terahertz Generation and 2-Photon Excitation.
  • Wavelength: 780 nm, 1560 nm
  • Average Power: >250 mW
  • Pulse Duration: <100 fs
  • Repetition Rate: 100 MHz
520 nm,1040 nm orange Femtosecond Ytterbium Laser.
Ultrafast Laser for Amplifier Seeding and Spectroscopy.
  • Wavelength: 520 nm, 1040 nm
  • Average Power: >10 W
  • Pulse Duration: <75 fs
  • Repetition Rate: 50 - 250 MHz
1560 nm ELMO Femtosecond Erbium Laser.
Ultrafast OEM Laser for Terahertz Generation.
  • Wavelength: 1560 nm
  • Average Power: >330 mW
  • Pulse Duration: <60 fs
  • Repetition Rate: 100 MHz
  • Smallest footprint on the market optimized for OEM integration
780 nm ELMO 780 Femtosecond Erbium Laser.
Ultrafast OEM Laser for 2 photon polymerization and Terahertz Generation.
  • Wavelength: 780 nm, 1560 nm
  • Average Power: >140 mW
  • Pulse Duration: <100 fs
  • Repetition Rate: 100 MHz
  • Smallest footprint on the market optimized for OEM integration
780 nm ELMO 780 XHP Femtosecond Erbium Laser.
Ultrafast OEM laser for 2 photon polymerization and multiphoton microscopy.
New
  • Wavelength: 780 nm, 1560 nm
  • Average Power: >1 W
  • Pulse Duration: <150 fs
  • Repetition Rate: 100 MHz
  • Compact footprint with integrated fast light modulation and dispersion precompensation
930 nm YLMO-930 Femtosecond Fiber Laser
for Microscopy and Life Sciences
  • Wavelength: 930 nm
  • Pulse Energy: >10 nJ
  • Repetition Rate: 50 MHz
  • Smallest footprint on the market optimized for OEM integration
1045 nm YLMO Femtosecond Ytterbium Laser.
Ultrafast Laser for Life Sciences.
  • Wavelength: 1045 nm
  • Average Power: >4 W
  • Pulse Length: <80 fs
  • Repetition Rate: 100 MHz
1030 nm YLMO-Seed Femtosecond Ytterbium Laser.
Ultrafast Seed Laser for Amplifier Seeding
  • Wavelength: 1030 nm and 1064 nm
  • Average Power: >200 mW
  • Bandwidth: 15 nm (others on request)
  • Repetition Rate: factory set between 30 MHz and 100 MHz
520 nm YLMO 520 Femtosecond Fiber Laser
for 3D Printing and Microscopy
New
  • Wavelength: 520 nm
  • Pulse Energy: >5 nJ
  • Repetition Rate: 100 MHz
3-5 µm YLMO Mid-IR Femtosecond Fiber Laser for
Mid-IR Spectroscopy
New
  • Wavelength: 3-5 µm
  • Average Power: >100 mW
  • Repetition Rate: 100 MHz
