Optical Frequency Synthesizer

MENLO SYSTEMS Optical Frequency Comb FC1000 250 3w


Advanced Features and Benefits

  • high repetition rate
  • fully fiber-coupled interferometer
  • operational range around 520 nm to 1040 nm
  • extended offset frequency tuning range
  • turnkey metrology system, fully automated with comb control and data acquisition software
Comb spacing 250 MHz
Accuracy 10-14 in 120 s or same as reference, whichever applies first
Stability 5x10-13 in 1 s or same as reference, whichever applies first
Tuning range of comb spacing >2 MHz
Tuning range of offset frequency >250 MHz
Wavelength range 520-1040 nm*

*inquire about different wavelength ranges


Frequency comb technology makes direct measurement of absolute optical frequencies possible. The FC1000 Optical Frequency Synthesizer is a compact, portable and flexible fiber-based femtosecond frequency comb system. The system is capable of providing at the same time a source for frequency metrology in both the visible and the near-IR regions (520-1040 nm) of the spectrum. A wide range of optional units enables us to tailor this versatile system to customer specific metrology solutions.


  • EOM-Phase EOM-Phase Electro-optic Phase Modulator

    Product Code: EOM-Phase

    Integrated into the laser cavity; allows high-performance phase locking to an optical reference by increasing the bandwidth of the repetition rate lock by more than an order of magnitude. With this EOM option sub-Hz line widths can be achieved. Required for high-performance phase locking to an optical reference.

  • FPC1000 Fabry Perot Cavity for Mode Filtering

    Product Code: FPC1000

    Increases the fundamental mode spacing to a user-defined frequency in the 2 to 25 GHz range. The Fabry-Perot is actively temperature stabilized and both input and output are fiber coupled.

  • M-520 High Power Measuring Port around 520 nm

    Product Code: M-520

    Output provides stabilized comb light with highest power at 520 nm. Contains an amplifier and subsequent frequency conversion, delivering minimum of 250 mW average power in a 3 nm window with a central wavalength at 520 nm.The output is free space.

  • BDU M-NIR Extension Package to the Near Inrfared Spectral Range

    Product Code: BDU

    Generates and measures the beat signal between the frequency comb and an external continuous wave (cw) laser. Available for various spectral ranges, with free space or fiber-coupled optics, and matched to the customer's laser.

    For more information: BDU

  • LLE-SYNCRO M-NIR Extension Package to the Near Inrfared Spectral Range

    Product Code: LLE-SYNCRO

    Allows locking of an external cw laser to the stabilized frequency comb. Performance has been field tested with lasers from major suppliers.

    For more information: LLE-SYNCRO

  • Microwave M-NIR Extension Package to the Near Inrfared Spectral Range

    Product Code: Microwave

    Ultrastable RF output in the 1 MHz-10 GHz range. Utilizing a high-sensitive fast photodetector and a frequency divider where needed.

  • GPS M-NIR Extension Package to the Near Inrfared Spectral Range

    Product Code: GPS

    Provides the RF reference input signal for the frequency comb, combining the superior short term stability of an ultrastable quartz oscillator with the long term accuracy of the GPS.

    For more information: GPS

  • WLM-NIR Wavelength Meter

    Product Code: WLM-NIR

    Integrated wavelength meter with 100 MHz accuracy at 900 - 1700 nm

  • WLM-VIS Wavelength Meter

    Product Code: WLM-VIS

    Integrated wavelength meter with 100 MHz accuracy at 500 - 1100 nm

  • SmartAmp SmartComb Extension

    Product Code: SmartAmp

    The SmartComb can be extended with a 19”, 3 HE rack containing up to 6 amplifiers, 6 beat detection units (BDU) and frequency counters. Using the SmartComb as a seed, the comb light is distributed and amplified with the SmartAmp. Together with internal BDUs and counters the system automatically measures your laser frequencies, in the range of 530-2000 nm, to the 14th digit. In addition, the beat signals serve as error signals to stabilize your CW laser (e.g. with a MenloSystems SYNCRO LLE unit) when required.

    In short: Stabilize all frequencies and transitions in your quantum optics laboratory to one absolute frequency reference!

    Menlo SmartComb SmartAmp 3w

  • Tablemounted SmartComb Extensions

    Product Code: Tablemounted Extension

    The SmartComb can provide stabilized comb output as a seed, thereby extending the range from 530 to 2000 nm with optional retrofittable extensions.

    Menlo SmartComb extended 3w
